DeltaQuad Evo Tactical Edition

The DeltaQuad Evo Tactical Edition VTOL UAV is an innovative aerial solution designed for security and defense applications.

NextSafety and Legal Notice

Last updated 3 months ago

Version number of this document: v3.1 - 7.12.2024

The Evo Tactical edition is designed for tactical use with a wide range of anti-interference systems. It is equipped with MANET Interference Avoidance enabled S-BAND radio with up to 80 km range, a 4 array CPRA Anti-Jamming GPS or 8 array, and a stealth switch system that allows full autonomous navigation without any radio emissions. The Advanced Data Safety software (ADS) prevents data disclosure of critical data, even with physical access to the vehicle.

The following is an overview of the main features.

Feature/Specification
DQEVO TAC

Max. flight time*

244 min

Max. flight range*

245 km/ 152 mi

Max. radio range

80 km

Ground control

Panasonic Toughbook

Radio options

Silvus-IA 2.2-2.5 GHz

ATAK compatible

ADS Software

Stealth switch

Interference Avoidance

Inertial Navigation

Resume mission

GNSS system

Anti-Jamming L1 GPS

*Measured at 0 meters Above Mean Sea Level (AMSL) at the takeoff location, 100 meters flight altitude, and 20 degrees Celsius with an auxiliary battery installed.

The DeltaQuad Evo Tactical is available with two optional GPS systems. Please refer to the following list for a comparison.

Feature/Specification
TUALAJ 4100-MINI CRPA 4-array
TUALAJ 8200 CRPA 8-array

GNSS bands

GPS, GALILEO, BEIDOU, SBAS

GPS, GLONASS, GALILEO, BEIDOU, SBAS

Simultaneous Independent Nulling

Against 3 jammers

Against 7 jammers (in 2 different frequency bands)

Signal Suppression

>40 dB

>50 dB

Environmental Tests

MIL-STD-810G

MIL-STD-810G

EMI / EMC

MIL-STD-461F

MIL-STD-461F

The DeltaQuad Evo Tactical manual is a comprehensive guide that delivers clear instructions, guidance, and essential information for users. This manual serves as an indispensable reference for covering the utilization, operation, assembly, and troubleshooting aspects of the DeltaQuad Evo Tactical. It presents detailed, step-by-step insights to ensure users gain a thorough understanding and can effectively implement the features of the DeltaQuad Evo Tactical.
